技术规格:
Input:
Input range:90Vac~264Vac
Frequency:47Hz~63Hz
Input current:1.0A Max at 100Vac input voltage
Efficiency:83% Min. at nominal input voltage, maximum load and measured at the end of DC cable
Output
Output Power:36W
Output Volts/Amps:12.0V/3.0A
Output ripple and noise:350 mV peak to peak
Dimensions (mm)
L85.0 x W36.0 x H26.3
