Technical specifications技术规格：
Input输入:
AC Socket:输入接口 ： C6 梅花尾
Input range输入电压范围：90Vac~264Vac
Frequency频率：47Hz~63Hz
Input current输入电流：2A Max at 100Vac input voltage
Efficiency效率：The power supply efficiency shall be more than 86.5% measure at the nominal voltagemaximum load,The AC input set at the normal voltage
Output输出
Output Power输出功率：120W
Output Volts/Amps输出电压/电流：19.0V/6.32A
Output ripple and noise输出纹波：350 mV peak to peak
DC Plug输出接口: 华硕Asus 6.0 X 3.5
此款有台达Delta logo,输出接口按客户项目需求提供
Dimensions (mm)尺寸
L160.0 x W76.20 x H25.4
