Technical specifications技术规格:
Input输入:
AC Socket输入接口: C6 梅花尾
Input range输入电压范围:90Vac~264Vac
Frequency频率:47Hz~63Hz
Input current输入电流:3.2A Max at 90Vac input voltagefficiency:89% Min. at nominal input voltage, maximum load and measured at the end of DC cable
Output输出
Output Power输出功率:65W
Output Volts/Amps输出电压/电流:Type-c with PD (5V 3A or 9V 3A or 15V 3A or 20V 3.25A )
Output ripple and noise输出纹波:350 mV peak to peak
DC Plug输出接口: type-c with PD function type-c带PD功能
Dimensions 尺寸(mm)
L66.0 x W66.0 x H28.5
